SteelGuard Straight with Narrow Lead Post

Won-Door SteelGuard Horizontal sliding, accordion-type fire door systems meet all IBC and NFPA criteria for use in a means-of-egress without occupant load limitations in all occupancy types except Group H.

Due to their wide span opening capabilities, the Won-Door SteelGuard horizontal sliding fire door allows for the unimpeded flow of pedestrian traffic as well as open plan designs. All Won-Door SteelGuard products are manufactured per application allowing for more freedom of design.

When the width of your strike wall is limited, a narrow leadpost on the SteelGuard door provides a secure and robust seal with a 4” recess. The narrow leadpost also allows for curved track configurations with a radius as tight as 5’.

Single parting configurations available
Unitized track system simplifies installation
Fire-rated up to 180 minutes
Pocket cover door provided by others
Automatic closing system in accordance with UL 864

Specification

Unique features of this fire door include:
UNITIZED TRACK SYSTEM
Unitized Track System (UTS) eliminates the layers of plywood and drywall found in conventional accordion fire door headers.
MOTOR DRIVE SYSTEMS
Automatic closing system listed in accordance with U.L. 864
STORAGE POCKETS
Doors up to 15'-0" tall only require 1'-6" wide pockets (For pocket depth use the Stack icon below product downloads)
ALTERNATIVE TO SIDE HINGED FIRE-DOORS
Won-Door SteelGuard doors are a single source assembly that eliminates the expense and associated maintenance costs of metal frames, astragals, etc.
POCKET COVER DOOR & BUMPER
Pocket cover door & bumper supplied by others.
SIZE LIMITATIONS
Won-Door SteelGuard doors with narrow lead posts are specifically designed for straight, single parting applications that are up to 40 feet wide and up to 15 feet in height. For widths greater than 40' and heights greater than 15' please see the FireGuard product line.

Technical specification

Unique ref.steelguard-straight-narrow-lead-post
Product familyDoors
Product groupFire Doors
TypeObject (single object)
Date of publishing2023-12-13
Edition number1

Links

Designed inUnited States
Manufactured inUnited States

Classification

BIMobject CategoryDoors - Sliding
Uniclass 2015 CodePr_30_59_24_28
Uniclass 2015 DescriptionFire doorsets
CSI MasterFormat 2014 Code08 35 13.23
CSI MasterFormat 2014 TitleAccordion Folding Fire Doors
OmniClass Number23-17 11 31
OmniClass TitleFire Doors
