300 Series Commercial Slat Door

ASTA AMERICA 300 SERIES COMMERCIAL SLAT DOOR is produced with the highest quality and durability in the industry. The 300 Series consists of 3” — 24 or 22-gauge slats with a flat or curved profile. The slats are commercial grade galvanized steel and coated with Super Durable polyester paint. Model 324, 24-gauge, is available in sizes up to 16’ wide x 16’ high. Model 322, 22-gauge, is available in sizes up to 12’ wide x 12’ high, both models are a perfect choice for freight terminals, commercial, and industrial applications.

Specification

FOUR FINISH OPTIONS:
- White Topcoat
- Gray Topcoat
- Tan Topcoat
- Galvanized
Powder Coat Finish is available in a variety of color options
40-year film integrity and a 35-year no-chalk/no-fade limited paint warranty.
STANDARD FEATURES:
- Roll formed 12-gauge galvanized guides
- Nylon endlocks
- Slide Bolt Locks
- Chain hoist operation
- Drum assembly with pre-installed curtain
OPTIONS
- Steel Mounting Plates: For lateral jamb extension to provide door support.
- Top Draft Stop: To seal tight at the header to reduce air infiltration.
- Guide Weather Seal: To seal tight at the jambs to reduce air infiltration.
- Vision Panels: 5” x 3/4” cut out spaced approximately 3” apart and covered with clear Lexan (flat slat only).
- Structural Steel Upgrade Guide: 3-piece structural steel guides.
- Windload: Available design to +40/-37 for 14’ wide (test) Model 324 (24- gauge). Windload varies by model.
- High Cycle Springs: Available in 50,000 cycles and 100,000 cycles.
