Climate Seal™ Magnetic Acoustic Series Window Insert
Climate Seal™ Magnetic Acoustic Series Window Insert
Climate Seal™ Magnetic Acoustic Series Window Insert
Climate Seal™ Magnetic Acoustic Series Window Insert
Climate Seal™ Magnetic Acoustic Series Window Insert
Climate Seal™ Magnetic Acoustic Series Window Insert
    Acoustical Surfaces, Inc.

    Climate Seal™ Magnetic Acoustic Series Window Insert

    Climate Seal™ Acoustic Series – Soundproof Window Inserts
    Discreet. Custom. Powerful.

    The Climate Seal™ Acoustic Series is a high-performance, nearly invisible window insert system designed to dramatically reduce unwanted noise without sacrificing aesthetics or functionality. Designed and intended to integrate seamlessly into residential, commercial, and historic applications, these inserts offer superior acoustic control, thermal insulation, and design flexibility — all at a fraction of the cost and disruption of full window replacement.

    Ideal for projects requiring exceptional sound attenuation, the Acoustic Series delivers significant and noticeable noise reduction with STC ratings as high as 49, outperforming many traditional and bulkier secondary glazing systems. Whether the need is to quiet a high-traffic urban street, block aircraft flyover noise, or create a peaceful interior for hotel guests or office tenants, Climate Seal™ provides an effective, low-profile solution.

    Key Benefits:

    • Outstanding Acoustic Performance: Reduces noise across all frequency levels with up to 80% sound reduction.
    • Maintains Aesthetic Integrity: Sits close to existing glazing and remains visually unobtrusive; custom finishes ensure design continuity.
    • UV Protection: Filters out up to 85% of harmful UV rays to protect interior furnishings.
    • Thermal Efficiency: Enhances the energy performance of existing windows by minimizing air leakage and thermal transfer.
    • Ease of Use: Simple, tool-free installation and removal for cleaning, maintenance, or fresh air — no permanent alterations required.
    • Custom Fit: Built to exact specifications for standard or uniquely shaped windows, with custom paint and glazing options available.
    • Emergency Egress: Easily removable in seconds to ensure accessibility during emergencies.

    Cost-Effective & Architecturally Compatible

    Unlike fixed secondary window systems that are bulky and intrusive, the Climate Seal™ Acoustic Series offers a refined, removable solution that delivers serious performance without compromising form or function. Its discreet presence makes it an excellent choice for noise-sensitive environments like apartments, schools, offices, recording studios, and heritage buildings where preservation of the original window is essential.

    Climate Seal’s Acoustic Series originated from our proven Thermal Series technology and has evolved to meet the exacting standards of the acoustical design community. When your project demands exceptional sound isolation without invasive construction or aesthetic trade-offs, Climate Seal™ Acoustic Series is the clear choice.

    Specification

    • SECTION 08 56 73

      Climate SealTM Window Inserts

      PART 1 GENERAL

      1. SECTION INCLUDES
        1. Climate SealTM acoustic and thermal window inserts and accessories for installation.
      2. REFERENCES
        1. American Society for Testing and Materials (ASTM)
          1. ASTM E90: Standard Test Method for Laboratory Measurement of Airborne Sound Transmission Loss of Building Partitions and Elements
      3. SUBMITTALS
        1. Product Data: Manufacturer’s data sheet and installation instructions.
        2. Samples: Submit, at minimum, a 4” x 4” sample for each type of specified window insert.
        3. Test Reports: Upon request, submit certified test reports to verify specified product performance.
      4. QUALITY ASSURANCE
        1. Qualifications:
          1. Manufacturers: Provide window inserts from a single manufacturer.
          2. Installers: Utilize an installer having demonstrated experience on projects of comparable size and complexity.
        2. Performance Requirements:
          1. Acoustical Characteristics: Window inserts to perform as specified when tested in accordance with ASTM E90.
      5. DELIVERY, STORAGE, AND HANDLING
        1. Storage and Handling Requirements:
          1. Handle window inserts carefully to avoid any damage.
          2. Store window inserts indoors in a clean, cool, dry place, and out of direct sunlight.
          3. Store window inserts in a space where the ambient temperature and humidity conditions are being maintained at the levels indicated for the project when occupied for its intended use.
      6. SITE CONDITIONS
        1. Ambient Conditions:
          1. Maintain ambient temperature and humidity conditions at levels indicated for the project when occupied for its intended use.
          2. Do not install products under environmental conditions outside manufacturer’s recommended limits.
        2. Existing Conditions: Do not install window inserts until space is enclosed and weather proofed, and wet work is completely dry.
      7. WARRANTY
        1. Provide manufacturer’s written product warranty per Section 01 77 00 – Closeout Procedures.

      PART 2 PRODUCTS

      (Specifier Note: Red colored text below requires you to select an option before this specification can be completed. Options in red text are bound by parenthesis. Additional Climate SealTM information can be found on our website: www.acousticalsurfaces.com

      1. MANUFACTURERS
        1. Climate Seal a Division of Acoustical Surfaces, Inc., 123 Columbia Court N, Chaska, MN 55318.
          Phone: 952-448-5300. Fax: 952-448-2613. Website: www.acousticalsurfaces.com
      2. DESCRIPTION
        1. Product: Climate SealTM acoustic and thermal window inserts by Acoustical Surfaces, Inc..
        2. Window Options:
          1. Window Size: As indicated on drawings
          2. Glazing Thickness: (Up to 5/16”)
          3. Glazing Options: (None) / (Tinted) / (Privacy) / (Abrasion Resistance) /
            (UV Filtering)
          4. Attachment: (Standard Angle) / (Inverted Angle) / (Flat Metal)
          5. Mounting Method: (In Jamb) / (Flush Mount)
        3. Window Frame Options:
          1. Frame Composition: Vinyl
          2. Frame Size: 3/4" width x 1” depth
          3. Frame Finish: (White) / (Brown) / (Painted Custom)
        4. Product Performance:
          1. Acoustical Performance
            1. Sound Transmission Classification (STC) per ASTM E90


    • Window Type with Climate Seal Insert

      STC Rating

      Double Hung

      37

      Triple Casement

      44

      Fixed Window with 2.5” Airspace

      38

      Fixed Window with 4.5” Airspace

      46

      Fixed Window with 6.5” Airspace

      51
      1. ACCESSORIES
      2. Attachment hardware for windows as specified by manufacturer for installation.

      PART 3 EXECUTION

      1. EXAMINATION
        1. Verification of Conditions:
          1. Examine openings, substrates, anchorage, and conditions.
          2. All wet work in the installation area must be complete, cured, and dry prior to installation.
          3. Wall assembly shall be complete, inspected, and accepted before window work begins.
      2. INSTALLATION
      3. Comply with manufacturer’s instructions and recommendations for installation of windows and with industry standards.
      4. CLEANING
      5. Clean surfaces of windows per manufacturer’s instructions or recommendations.
      6. Clean surfaces immediately after installing windows. Avoid damaging protective coatings and finishes.
      7. PROTECTION
      8. Protect installed work from damage due to subsequent construction activity, including temperature and humidity limitations and dust control, so that the work will be without damage and deterioration at the time of acceptance by the owner.

      END OF SECTION

    Technical specification
    • Unique ref.nst14691
    • Product familyWindows
    • Product groupSound Control Windows
    • TypeObject (single object)
    • Date of publishing2013-08-07
    • Edition number1
    Links
    Classification
    • BIMobject CategoryBuilding Materials - Insulation
    • IFC classificationWindow
    • Uniclass 2015 CodeSs_25_30_95_41
    • Uniclass 2015 DescriptionInternal window systems
    • CSI MasterFormat 2014 Code09 80 00
    • CSI MasterFormat 2014 TitleAcoustic Treatment
    • OmniClass Number23-17 19 15 11 11
    • OmniClass TitleAcoustic Seals
    • CSI UniFormat II CodeC10
    • CSI UniFormat II TitleINTERIOR CONSTRUCTION
