Hörmann

Hörmann’s fully parametric high-performance and commercial sectional door families are now available for Autodesk Revit, giving Architects, Engineers, and Designers real-time product data and instant design feedback.

Designed with your workflow in mind, our Revit content empowers you to make confident, precise decisions-quickly. Explore, download and learn more at www.hormann.us.

Key Features of Hörmann Revit Families

Parametric Flexibility

Adjust door sizes directly in 2D plans,
elevations & sections using shape
handles or instance parameters.

Tolerance Warnings

If input dimensions exceed manufacturing
limits, graphic alerts appear in 3D &
elevation views, with notes in 2D plans.

Offset Placement

Doors can be offset from the host wall to meet project-specific needs.

Built-In Clearance Guidance

Toggle the Clearance Area parameter to
show recommended installation space for
accurate placement.

Optional Hood Visibility

Show or hide Top Assembly Enclosures
using the Construction Group
Parameters.

Live Structural Load Data

Structural loads are calculated based on
door size and options, ready to share with
consultants.

WYSIWYG Model Accuracy
What you see is what you get - Door
panels adjust automatically based on
height per manufacturing specs.

Vision Panel Control
Auto-populating vision panels can be
customized or removed using Window P#
parameters.

Render-Ready Materials
Materials are both visually accurate and
analytically correct for photorealistic
rendering.

Electrical Control Box Integration
Control Boxes are circuit-ready and include precise electrical data. Placement can be adjusted using shape handles in plan and elevation views or hidden as needed.

Optimized for Drawings at Any Scale
Door families include adjustable levels of detail (Coarse, Medium, Fine) for clean graphics from plans to details. Carefully selected line weights and materials ensure visual consistency in all views.

Download and Design with Confidence
Start your next project with high-performance BIM content that’s easy to use, technically robust, and visually polished. Download now, and also at www.hormann.us.
