OWA - Odenwald Faserplattenwerk GmbH

Brillianto100

The Brillianto100 mineral ceiling offers maximum sound absorption, ensuring excellent speech intelligibility in the room. At the same time, the system meets the highest standards of responsible material selection thanks to its 100% recyclability through the OWA green circle closed material cycle. Combined with good fire resistance up to REI 45, the triple-laminated suspended ceiling ensures greater safety and well-being in the long term.

Specification

Mineral tile Brillianto100
Name: OWAcoustic mineral tile Brillianto100
Collection: OWAlifetime collection
Manufacturer: OWA
Application: Ceiling system S 3, S 3 cliq, S 3a, S 3a cliq, S 15 cliq, S 15a cliq

Technical data:
Mineral tile according to DIN EN 13964 and DIN 18177
Proof of usability in accordance with EU Construction Products Regulation:
CE marking and Declaration of Performance (DoP)
Air permeability class: PM 1
Formaldehyde class: FH 1
VOC emissions: TVOC 1
Design: Brillianto100, fleece-covered
Colour: white, finished
Light reflection: approx. 78 (ISO 7724-2, ISO 7724-3)
Reaction to fire: A2-s1,d0 according to DIN EN 13501-1
Edge: 3, Square edge | 6, revealed edge 24 mm grid | 15, revealed edge 15 mm grid
Thickness: 15 mm nom.
Sound absorption:
Alpha w = 1,00
NRC = 0,95
Sound reduction:
Dn,f,w = 22 dB
CAC = 23 dB
Humidity resistance: up to 95% RH

Technical specification

Unique ref.Brillianto100
Product familyMineral ceilings
Product groupExposed systems
TypeObject (single object)
Date of publishing2025-10-02
Edition number1

Links

Product urlhttps://www.owa.de/en/produkt/brillianto100-br100-en/
Installation instructionshttps://www.owa.de/wp-content/uploads/2018/12/DS_9801.pdf
Instruction videohttps://www.owa.de/de/service/videos/
Technical descriptionhttps://www.owa.de/wp-content/uploads/2025/08/DB_Brillianto100_d.pdf
Tendering informationhttps://ausschreiben.de/catalog/owa

Related

Material mainMineral
Material secondaryMetal
Designed inGermany
Manufactured inGermany

Classification

BIMobject CategoryBuilding Materials - Acoustic Panels & Accessories
IFC classificationCeiling
Uniclass 2015 CodeSs_30_25_22
Uniclass 2015 DescriptionDemountable suspended ceiling systems
CSI MasterFormat 2014 Code09 51 23
CSI MasterFormat 2014 TitleAcoustical Tile Ceilings
OmniClass Number23-15 19 15 11 11
OmniClass TitleAcoustical Ceiling Tile
