Toilet cisterns PUCCI ® eco ® 9l -4l

TWO PUSH-BUTTONS FLUSH TANK FOR BRICK WALLS - FOR FLOOR MOUNTED BOWL 1315490001

FIELDS OF APPLICATION

规格

FEATURES AND EQUIPMENT - Polyethylene tank 7,5 cm total thickness - Plaster holder pre-built mesh - Front control with two quantities rinsing - Water connection from above misaligned on the left - 1/2” stop cock with support - 4 supporting brackets with tank fastening screws - 35 x 11 cm adjustable flush pipe (+2-2 cm) - Foam protection, covers and cap for rinsing pipe adjustment - Eccentric escutcheon and 22 cm joint - Ø 48-58 mm combined clamp with clamp cover - From Ø 40 mm to Ø 45 extension socket, OR 143 and Ø 55-44 mm clamp - Gasket lubricant package - Foam protection for door and inner parts - Anti-condensation TECHNICAL DATA dynamic pressure 0,1-10 bar maximum water temperature 25°C rinsing quantity predetermined setting - out 9-4l long - rinsing regulation range 9-6l short - rinsing regulation range 4-3l

技术规格
