AEROPAN

AMAGEL A2

Amagel A2 represents a new major step in the development of silica Aerogel-based nano-technological insulating products. It consists in a fibreglass-based flexible insulating matrix and a high concentration of nanoporous aerogels, able to ensure the very best heat performance in any condition of application. In the quest for utmost heat protection, AMAGEL A2 stands as an essential insulating product thanks to its unique properties: • extremely low heat conductivity – 0.015 W/(m*K)-, • superior flexibility, • compression resistance, • hydrophobicity and ease of use. AMAGEL A2 can be used within a temperature range of -50°C and +450°C. AMAGEL A2, available in thicknesses from 3 to 60 mm, permits optimizing interior spaces in building applications for commercial and residential buildings, providing the very highest values of heat resistance – thickness being equal – compared to insulating materials of conventional type. Its use permits achieving major results in complex situations, e.g., in insulating windows or roof sections, resulting in an effective increase in the total energy efficiency of the building with excellent heat and acoustic insulation results. Thanks to maximum R values per unit of surface compared to any other insulating material, AMAGEL A2 is the ideal covering for achieving extremely high energy performance in making dry walls, under floors and roofs, mock frames and window frames. Unlike rigid and preformed insulation, AMAGEL A2 adapts perfectly to any shape or design: the blanket is flexible, physically sturdy, but with excellent shape and project performance recovery even after any load compression. Its specific composition also ensures the best fire resistance performance (Euroclass A2) thus permitting use even in very heavy-duty conditions and where superior performance levels are required. AMAGEL A2 has achieved the CE label which attests the compliance to all the requirements in the energetic area, to the performances required by the European Union and satisfying the strictest standard of quality and safety.

Özellikler

SPECIFICATIONS FOR THERMAL INSULATION INSTALLATION The installation will consist of thermal insulation panels made of silica aerogel reinforced with partially recycled glass fiber (felt), compliant with CAM regulations and certified according to ISO14021:2016, type Amagel A2 hydro-repellent and breathable, supplied in panels of 1450×750 mm, with a nominal thickness of 10/20/30/40/50/60 mm, with a volumetric density of 200 kg/m3, a thermal conductivity of 0.015 W/mK, and a working temperature range between -50°C and +450°C. The fire reaction is Euroclass A2 S1D0, permeable to water vapor diffusion (Sd= 0.07), impermeable to surface and/or immersion water with a water contact angle not less than 150°, and certified as Class A+ for VOC emissions. The product is CE marked according to ETA 20/0562 dated 16/07/2020. The thermal insulation panels are suitable for dry applications, cavity walls, roofing, underfloor heating, and for insulating complex surfaces. TYPES AND FORMATS 2 different Amagel A2 formats are available for use wherever a low level of dust is required, typical characteristic of Aerogel-based products. Amagel A2 rolls are available in thicknesses of 3 mm, 6 mm and 10 mm. Amagel A2 panels are available in thicknesses of 10 mm, 20 mm, 30 mm, 40 mm, 50 mm and 60 mm.

Teknik özellikler

Benzersiz ref.AMAGEA3
TipObje (Tekil Nesne)
Yayınlanma tarihi2025-10-14
Baskı numarası1

Bağlantılar

Ürün URL’sihttps://aeropan.it/en/service/amagel-a2-en/
Teknik açıklamahttps://aeropan.it/wp-content/uploads/2025/09/Technical-data-sheet.pdf

İlgili

Tasarım yeriİtalya
Üretim yeriİtalya

Sınıflandırma

BIMobject kategorisiİnşaat Malzemeleri - Yalıtım
IFC sınıflandırmasıYapısal Eleman
OmniClass numarası23-13 25 19
OmniClass başlığıThermal Insulation
