    Armatherm™ 500 Series Column Base Thermal Bridging US

    Column Base Thermal Bridging Solution

    Internal steel columns traditionally extend through the building envelope floor slab and insulation at their base. In low temperature buildings such as freezer rooms and cold storage facilities, this creates a thermal bridge and point transmittance (heat loss) at the steel column base. This is also the case for exterior columns which support floors or roof overhangs. The column to roof connection interrupts the continuous insulation creating heat loss due to thermal bridging.

    Specifikation
    • Column Base Thermal Break

    Teknisk specifikation
    • Unik ref.armatherm-500-column-base-thermal-bridging
    • ProduktfamiljArmatherm™ 500
    • ProduktgruppStructural Thermal Break
    • TypByggmaterial
    • Publiceringsdatum2024-04-25
    • Edition nummer1
    Relaterad
    • HuvudmaterialPolyuretan
    • Designad iUSA
    • Tillverkad iUSA
    Klassificering
    • BIMobjektkategoriByggnadsmaterial - Isolering
    • IFC klassificeringKonstruktionsanslutning
    • ETIM kodEC000406
    • ETIM namnThermal insulation
    • UNSPSC namnThermal insulation
    • UNSPSC kod301415
    • Uniclass 2015 kodPr_35_90_15_89
    • Uniclass 2015 beskrivningThermal break connection plates
    • CSI MasterFormat 2014 Kod07 21 00
    • CSI MasterFormat 2014 TitelThermal Insulation
    • OmniClass nummer23-13 25 19
    • OmniClass TitelThermal Insulation
