Passive House Certified Fixed Windows
Passive House Certified Fixed Windows

    Passive House Certified Fixed Windows

    Traduzido pelo Google,

    O Sistema Defender 88PH+ combina décadas de conhecimento em fenestração para oferecer um sistema robusto de janelas e portas com certificação do Passive House Institute (PHI). Nossas janelas para casas passivas são fabricadas no Canadá para projetos de casas passivas na América do Norte.

    Especificação
    • A History of Performance

      Innotech Windows + Doors was established at the turn of the century with the purpose of manufacturing German engineered windows and doors that reached beyond industry standards. Today, we are proud to offer our clients a full line of high-performance, energy-efficient and durable windows and doors that are engineered, tested and labeled for our North American climate and building codes.

      Passive House Certified Windows

      The Defender 88PH+ System is a natural evolution in our history. It offers the performance required to achieve the ultimate in energy-efficient design and construction: the Passive House Standard as defined by the International Passive House Association. Manufactured at our state-of-the-art manufacturing facility in Langley, British Columbia, the Defender 88PH+ System is a Passive House Institute (PHI) and Passive House Institute US (Phius) certified component with outstanding thermal insulation, superior air, water and sound resistance, and proven durability.

      Defender 88PH+ XI – Fixed Window

      • Passive House Institute certified component for climate region 2 (cold climate)
      • Phius certified product for climate zone 7
      • PHI Uw value = 0.59 W/(m²K)
      • available with a variety of glazing, finish and hardware options
      • NFRC rated, NAFS tested and manufactured in Canada

      Defender 88PH+ Pro – Fixed Window

      • Passive House Institute certified component for climate region 3 (cool temperate climate)
      • Phius certified product for climate zone 6
      • PHI Uw value = 0.75 W/(m²K)
      • available with a variety of glazing options
      • NFRC rated, NAFS tested and manufactured in Canada

      Key Performance Data

      The Defender 88PH+ System performance data is available for download on the Passive House Institute’s Components Database and on the Phius Certified Product Database. Contact us for additional information, including NFRC and NAFS values.

    Especificação técnica
    • Ref. únicapassive-house-certified-fixed-windows
    • Família de produtoWindows
    • Grupo de produtosPassive House Certified Windows
    • TipoObjeto (objeto único)
    • Data de publicação2025-08-18
    • Número da edição1
    Afins
    • Material principalPVC
    • Material secundárioAço galvanizado
    • Desenhado emCanada
    • Fabricado emCanada
    Classificação
    • Categoria BIMobjectJanelas - Janelas de estrutura fixa
    • Classificação IFCJanela
    • Código Uniclass 2015Pr_30_59_98
    • Descrição Uniclass 2015Window units
    • CSI MasterFormat 2014 Code08 50 00
    • Título CSI MasterFormat 2014Windows
    • Número OmniClass23-17 13 00
    • Título OmniClassWindows

    Disponibilidade regional

    América do Norte
    Canada
    United States
