Housing
Extruded aluminum with die-cast end plates
Shielding
Extruded, flat, diffuse acrylic lens
Finish
Textured matte white polyester TGIC powder coat bonded to phosphate-free, multi-stage pretreated metal. All parts painted after fabrication to facilitate installation, increase efficiency, and inhibit corrosion
Electrical
High-quality mid-power LED boards. Reported L70: >54,000 hours. Reported L90: 52,000 hours. Estimated L70: 170,000 hours. 25°C maximum ambient operating temperature. 50/60 Hz constant current driver.
Mounting
Wall mount. Powder coated, die-formed C.R.S. receiving bracket mounted to fixture which attaches to wall mounted bracket.
Listings
- cCSAus certified as luminaire suitable for dry or damp locations
- ADA Compliant
- UL 924 available
- Build America, Buy America (BABA) and Buy American Act (BAA) compliant
- Request certification at hew.com/buy-American
Warranty
5-year limited warranty.
