Thermostatic single lever mixer F4LT1025

F4LT-Med thermostatic single lever mixer as DN 15 wall-mounted mixer, for wall mounting with lockable swivelling spout, for surgical sanitary facilities and unclean work spaces in the healthcare and nursing sector, lever length 251 mm. Thermostat-controlled mixer cartridge with expansion element and active scald protection, fail-safe against backflow as well as adjustable, turn-proof temperature stop, ceramic disc technology and flow rate controller 9.0 l/min. Without backflow preventer for optimised drinking water hygiene. Lever cap ergonomically designed in closed construction for contactless lever actuation. For connecting to hot and cold water. Tap optimised for cleaning, scald-protected, safe-touch housing, all-metal construction, polished chromium-plated brass. Decoupled from the tap housing, volume-reduced, smooth water flow from low-lead brass (lead proportion ≤ 0.2%), and without nickel coating. With thermal insulation components to reduce heat transfer from the tap housing to the cold-water line. Self-emptying spout with laminar jet controller. With adjustable and lockable connections with strainers, fully covered by depth-adjustable screw rosettes. 285 mm projection.

Specificatie

Depressurised	no
Functional principle	manual
Diameter nominal	DN 15
Inlet size	G 1/2 B
Locking mechanism	Top section, ceramic
Material fitting	brass-look
Minimum flow pressure	1 bar
Type of mixing	with thermostat
Overall width	220 mm
Pop-up waste set	no
Spout	rotating, bottom
Spout projection	200 mm
Surface finish casing	chromed
Surface finish fitting	chromed
Surface treatment fitting	polished
Temperature limit	yes
Type of mounting	wall mounting
Type of operation	manual operation
Type of tap	bib tap
Volume flow rate at 3 bar	0.15 l/s
Water connection	S-unions
Accent colour	none
Basic colour	chrome-look (glossy)

Technische specificatie

Unieke ref.2030072408
ProductfamilieTaps
ProductgroepManual taps medical
TypeObject (enkelvoudig object)
Publicatiedatum2024-10-10
Editienummer1
Breedte (mm)220

Links

Product-urlhttps://kwc-professional.com/en/f4lt-med_p2030072408
Installatie-instructieshttps://stpkwcprodaks01.blob.core.windows.net/public/assets/products/2030072408/mounting-instruction_3700022939.pdf

Gerelateerd

HoofdmateriaalMessing
Ontworpen inDuitsland
Gefabriceerd inDuitsland
Nettogewicht (kg)3.71

Classificatie

Categorie BIMobjectSanitair - Tap/Kraan/Koperwerk
Uniclass 2015-codePr_40_20_87_98
Uniclass 2015-beschrijvingWashbasin taps
