Thermostatic single-lever wall-mounted mixer F4LT1005

F4LT-Med thermostatic single lever mixer as DN 15 wall-mounted mixer for wall mounting with lockable swivelling spout, for sanitary facilities in the healthcare and nursing sectors, with 148 mm lever. Thermostat-controlled mixer cartridge with expansion element and active scald protection, fail-safe against backflow as well as adjustable and turn-proof temperature stop, and ceramic disc technology. Without additional backflow preventer for optimised drinking water hygiene. Lever cap with an ergonomic bracket design and slight curvature in the front with basalt-grey coating, in line with two-senses principle (tactile and visual). For connection to hot and cold water. Tap optimised for cleaning, scald-protected, safe-touch housing, all-metal construction, polished chromium-plated brass. Decoupled from the tap housing, volume-reduced, smooth water flow from low-lead brass (lead proportion ≤ 0.2%), and without nickel coating. With thermal insulation components to reduce heat transfer from the tap housing to the cold-water line. Self-emptying spout with flow rate controller 9.0 l/min and laminar jet controller. With adjustable and lockable connections with strainers, fully covered by depth-adjustable screw rosettes. Projection 200 mm.

Specificatie

With backflow preventer	no
Depressurised	no
Adjustable flow time	no
Functional principle	manual
Hygiene flushing	no
Diameter nominal	DN 15
Inlet size	G 1/2 B
Locking mechanism	Top section, ceramic
Material fitting	brass-look
Minimum flow pressure	1 bar
Type of mixing	with thermostat
Pop-up waste set	no
Protective shutdown	no
Surface finish casing	chromed
Surface finish fitting	chromed
Surface treatment fitting	polished
Temperature limit	yes
Type of mounting	wall mounting
Type of operation	manual operation
Type of tap	bib tap
Volume flow rate at 3 bar	0.15 l/s
Water connection	S-unions
Accent colour	none
Basic colour	chrome-look (glossy)

Technische specificatie

Unieke ref.2030066753
ProductfamilieTaps
ProductgroepManual taps medical
TypeObject (enkelvoudig object)
Publicatiedatum2024-09-24
Editienummer1
Breedte (mm)220

Links

Product-urlhttps://kwc-professional.com/en/f4lt-med_p2030066753
Installatie-instructieshttps://stpkwcprodaks01.blob.core.windows.net/public/assets/products/2030066753/mounting-instruction_2030068381.pdf

Gerelateerd

HoofdmateriaalMessing
Ontworpen inDuitsland
Gefabriceerd inDuitsland
Nettogewicht (kg)3.71

Classificatie

Categorie BIMobjectSanitair - Tap/Kraan/Koperwerk
Uniclass 2015-codePr_40_20_87_98
Uniclass 2015-beschrijvingWashbasin taps
