Brava

Synthetic Slate Roofing

Elegance and durability of natural slate with all the benefits of composite roof tile, at a fraction of the cost.

If you're looking for the incredible aesthetics of natural quarried slate roofing and want to avoid costly substructure modifications required to handle the extreme weight of slate tiles, Brava’s revolutionary composite slate tile is for you. Brava Slate is available in 12" standard slate and 6", 9", and 12" multi-width slate sizes.

Voce di capitolato

Dimensions

Length	22"
Width	12" (6", 9", 12": Multi-Width Slates)
Thickness	1"
Maximum Exposure	10"
Minimum Keyway	3/16" (3/8" Recommended)
Minimum Sidelap	1-1/2"

Weight

Weight/Piece (lb.)	1.4 (6”); 1.8 (9”); 2.7 (12”)
Lb./Square	311
Lb./Pallet	1836

Packaging

Pieces/Bundle	10 (12")
Pieces/Bundle (Multi-Width)	12 (3 x 6", 3 x 9", 6 x 12")
Bundles/Square	11.5
Bundles/Pallet	66
Squares/Pallet	5.74

Testing Class A

Weatherometer	Pass
Fire Resistance	Class A
Impact Resistance	Class 4
Wind Resistance	All tiles are manufactured to uphold the highest quality control standards and withstand the harshest of weather conditions. Brava tiles are tested and approved to withstand wind speeds of up to 188MPH with ring shank nails and up to 211MPH with high wind / screw installation.
Uplift Bend	Pass
Temperature-Cycling	Pass
Penetration	Pass

Testing Class C

Weatherometer	Pass
Fire Resistance	Class C
Impact Resistance	Class 4
Wind Resistance	All tiles are manufactured to uphold the highest quality control standards and withstand the harshest of weather conditions. Brava tiles are tested and approved to withstand wind speeds of up to 188MPH with ring shank nails and up to 211MPH with high wind / screw installation.
Uplift Bend	Pass
Temperature-Cycling	Pass
Penetration	Pass

Code Compliance

Miami-Dade Approved	Yes
Florida Building Code Approval (FBC)	Yes
Title 24 / Cool Roof Approval	Terra Cotta, French Clay, Weathered, Lake Forest colors only
International Building Code (IBC) Compliant	Yes
International Residential Code (IRC) Compliant	Yes

Specifiche tecniche

Rif. Unicosynthetic-slate-roofing
Famiglia di prodottoRoofing Products
Gruppo di famigliaSlate
TipoOggetto (oggetto singolo)
Data di pubblicazione2025-10-30
Numero di versione1

Links

Link al Prodottohttps://www.bravarooftile.com/roof-tiles/old-world-slate/
Istruzioni di installazionehttps://www.bravarooftile.com/resources/brava-old-world-slate-roof-tile-installation-pdf/
Video di istruzionehttps://youtu.be/9yJ6s6iDvZY
Descrizione Tecnicahttps://www.bravarooftile.com/resources/product-data-sheet-old-world-slate-2-0-spec-sheet-product-comparison/

Relativo a

Progettato inStati Uniti
Prodotto inStati Uniti

Classificazioni

Categoria BIMobjectEdilizia - Coperture, tetti e tegole
Clasificazione IFCTetto
Codice ETIMEG020300
Nome ETIMBuilding - Roofing materials
Codice Uniclass 2015EF_30_10
Descrizione Uniclass 2015Roofs
Codice CSI MasterFormat 201407 31 26
Titolo CSI MasterFormat 2014Slate Shingles
Numero OmniClass23-13 39 19 11
Titolo OmniClassRoof Slates
