Slim Indoor/Outdoor Flexible Linear LED Light Strip

Alcon Lighting

Slim Indoor/Outdoor Flexible Linear LED Light Strip

Alcon Lighting’s 14145 slim indoor/outdoor flexible linear LED light strip delivers high-lumen illumination for commercial, hospitality, retail and residential applications. The IP65-rated strip light provides up to 140 lumens per foot in static 2700K, 3000K, 4000K or Blue, bending seamlessly along horizontal surfaces for continuous runs up to 32 feet. Constructed with a silicone housing and factory-sealed connectors, the system ensures durability indoors or outdoors. Compatible with MLV, ELV, 0-10V and TRIAC dimming, this LED light strip offers versatile, specification-grade control for architectural accent lighting.

Voce di capitolato

Construction: Silicone
Max run: Continuous run length up to 32 ft.
Cuttable: Every 3.94”
Mounting channels: 2" aluminum, 39" aluminum, 39" flexible aluminum, 39" plastic, 39" flexible profile (white or black)
Voltage: 24V DC Constant Voltage
External dimming driver: 0-10V, MLV, ELV, and TRIAC
Power consumption: 4.4 W/ft
Lumens: 140 lm/ft
Beam angle: 160°
Color temperature (CCT): 2700K, 3000K, 4000K, Blue
CRI: 88+
Operating temperature: -40ºF (-40°C) to 131ºF (55°C)
Humidity: 0-95% non-condensing
Life: 50,000 Hours
Listing: UL Listed, IP65
Warranty: 5 years carefree for parts & components (labor not included)

Specifiche tecniche

Rif. Unico14145-flexible-strip-light
Famiglia di prodottoIndoor-Outdoor Lighting
Gruppo di famigliaPerimeter Lighting
TipoOggetto (oggetto singolo)
Data di pubblicazione2025-11-21
Numero di versione1

Links

Link al Prodottohttps://www.alconlighting.com/alcon-14145.html
Istruzioni di installazionehttps://www.alconlighting.com/media/product_files/alcon_lighting/14145-Installation-Instructions.pdf
Descrizione Tecnicahttps://www.alconlighting.com/media/product_files/alcon_lighting/14145_specification-sheet.pdf
