Pinnacle Clad – Casement & Awning
Pinnacle Clad – Casement & Awning
Pinnacle Clad – Casement & Awning
Pinnacle Clad – Casement & Awning
Pinnacle Clad – Casement & Awning

    Pinnacle Clad – Casement & Awning

    Our top-of-the-line Pinnacle clad and wood windows and doors offer a large selection of styles and shapes. The exterior comes in a low maintenance extruded aluminum cladding. You can choose from:

    • 22 standard colors
    • 20 feature colors

    The interiors of our Pinnacle product lines are made from the finest woods available, including Clear Select Pine, Natural Alder or Douglas Fir.

    Pinnacle Clad – Casement & Awning

    • Warmth and beauty of Clear Select Pine, Natural Alder or Douglas Fir interior; can be painted or stained
    • Clad units offer a strong, durable extruded aluminum exterior sash and frame for low-maintenance
    • 2" thick sash adds beauty and increases insulating value
    • Single lever multi-point lock for easy operation and clean appearance
    • Adjustable hinge system ensures smooth operation
    Technical specification
    • Unique ref.windsorwindows-0001
    • Product familyWindows
    • Product groupPinnacle Clad
    • TypeObject (single object)
    • Date of publishing2017-01-20
    • Edition number1
    Related
    • Material mainWood
    • Material secondaryAluminium
    • Designed inUnited States
    • Manufactured inUnited States
    Classification
    • BIMobject CategoryWindows - Awning Window
    • Uniclass 2015 CodeEF_25_30
    • Uniclass 2015 DescriptionDoors and windows
    • CSI MasterFormat 2014 Code08 51 00
    • CSI MasterFormat 2014 TitleMetal Windows
    • OmniClass Number23-17 13 13
    • OmniClass TitleMetal Windows
    • CSI UniFormat II CodeB2020
    • CSI UniFormat II TitleExterior Windows

    Region availability

    North America
    Canada
    Mexico
    United States
