EcoPower® Ultra-High-Efficiency Toilet Flush Valve - 1.0 GPF (V.B. Set)

EcoPower® Ultra-High-Efficiency Toilet Flush Valve - 1.0 GPF (V.B. Set)

The water-powerd turbine in the EcoPower flush valve charges the power supply during usage and provides maximum performance in even the most demanding, high-traffic commercial spaces. A special version of this flush valve works with reclaimed water systems.

Specification

- 1.0 GPF
- Self-powered hydroelectric flush valve system
- No minimum daily usage requirement
- Durable chrome plated body with tamper-proof screws and solid bronze valve body
- Self-cleaning piston valve with 360° filter screen
- Neutral rough-in and adjustable tail piece connection
- True mechanical flush override
- Smart sensor with self-adjusting detection range
- 6-second detection time to prevent ghost flushing
- For toilet with 1-1/2" top spud inlet
- Exposed flush valve with 1" angle stop and 1-1/2" vacuum breaker set
- ADA compliant
- Model available for use with Reclaimed Water Systems (See options above)
- EPD coated valve body (Reclaimed Water Model)
- See product Spec Sheet (X) version for Reclaimed Water Quality Parameters

Technical specification

Unique ref.TET1LA32_EcoPower_Ultra-High-Efficiency_Toilet_Flush_Valve1GPF
Product familySanitary
Product groupFlush valves
Date of publishing2024-10-31
Edition number1
Height (inches)11.5
Width (inches)3.3

Links

Product urlhttps://www.totousa.com/ecopower-high-efficiency-toilet-flush-valve-128-gpf-vb-set
Installation instructionshttps://www.totousa.com/filemanager_uploads/product_assets/OwnersManual/0GU3062_Flush-Valve_EcoPower_Exposed.pdf
Product certificationhttps://www.totousa.com/filemanager_uploads/product_assets/OwnersManual/Li-Battery-Test-Summary-THP3053-EFVEPF.pdf
Technical descriptionhttps://www.totousa.com/filemanager_uploads/product_assets/SpecSheet/SS-01219_TET1UA.pdf

Related

Material mainChrome
Material secondaryBrassware

Classification

BIMobject CategoryPlumbing - Valves
