Arch Window Transaction Line System

TSS Arch Style Transaction Line

The TSS Arch Style Transaction Line creates a large arch opening for sound to travel, while protecting against shooting lanes and giving a sleek look. Using a cutout in the glazing wall section, a broader “Arch Style” window is utilized and spaced 1½” from the main glazing wall section. Commonly used for bank branches, reception areas, and service counters.

Options

Available in Acrylic, Polycarbonate, and GCP
Intended for interior purposes
Rated or non-rated channel available

Ratings

UL Levels 1–5 (Glazing)
UL Levels 1–7 (Variety of channel available)

Standards

UL 752: Standard for Bullet Resistant Materials
NSI Z971-1984: Safety Glazing Materials for Building
ASTM C1036: Standard Specification for Flat Glass
ASTM C1172: Standard Specification for Laminated Architectural Flat Glass
ASTM D4802: Standard Specification for Poly(Methyl Methacrylate) Acrylic Plastic Sheet

Technical specification

Unique ref.arch-window-transaction-line-system
Product familyBullet Resistant Transaction Windows
Product groupBullet Resistant Transaction Window
TypeObject (single object)
Date of publishing2025-11-06
Edition number1

Links

Classification

BIMobject CategoryWindows - Ticket Windows
