    SE Controls

    OS3 Standard Manual Control Point

    Features

    The MCP is designed to allow the Fire & Rescue Service to manually override the smoke control system through a user-friendly

    interface. Design includes an open button and a close/reset button, which are accessed by lifting the clear front door.

    Designed to meet prEN12101 part 9.

    Environmental Control & Sensor Integration

    OS3 MCPs include a built-in thermistor for real-time temperature monitoring, enabling precise environmental control. Universal I/O connections support integration with rain sensors, air temperature sensors, and fire alarms.

    A local microcontroller handles signals and actuators directly at the MCP, reducing reliance on central panels and simplifying system design.

    Installation & Compliance Advantages

    Addressable backplates and built-in control logic reduce hardware needs and speed up commissioning.

    The system retains settings during upgrades or replacements, while EMC compliance ensures reliable performance in tough environments.

    Specification
    • Device Details
      Provided in orange (RAL 2011) as required as part of prEN12101-9
      The device has the capabilities of providing audible signals and faults, along with having a silence
      button out of view
      The OS3MCP continuously monitors actuators and connections to smoke detectors (As required
      as part of prEN12101-9)
      Maintenance indication (Statutory requirement of the Regulatory Reform Order (Fire Safety)
      Cover reset push button via access key fob
      Reset push button
      Activated LED
      Power/Healthy LED
      Fault LED
      Single action activation cover (replaces glass frangible element)
    Technical specification
    • Unique ref.SECBIM0033
    • Product familyControl Systems
    • Product groupSwitches
    • TypeObject (single object)
    • Date of publishing2026-03-02
    • Edition number1
    • Height (mm)87
    • Width (mm)87
    • Depth (mm)51
    Links
    Related
    • Material mainABS
    • Material secondaryAcrylic
    • Designed inUnited Kingdom
    • Manufactured inUnited Kingdom
    • Weight Net (Kg)0.1
    Classification
    • BIMobject CategoryElectronics - Controls
    • IFC classificationSwitching Device
    • Uniclass 2015 CodePr_75_51_17_66
    • Uniclass 2015 DescriptionPush button switches
