CYCLONE® Roof Drain | RPH (Roof Penetration Housings, LLC)

The CYCLONE® Roof Drain is a highly efficient solution that rapidly drains rainwater from flat or low-slope roofs, mitigating the risk of water accumulation and structural damage. Its design facilitates high flow rates, minimizing the potential overflow during heavy rainfall or in regions prone to hurricanes, tornadoes, or high wind events.

Specification

- Primarily for poured-in-place (suffix “PP”) applications: Precast (suffix “PC”) models also available
- Meets ANSI standards for size and ASPE GPM discharge
- For safe room/storm shelter applications, third-party tested to meet ICC-500 2014 and FEMA P-361 to 250+ mph wind, including
  missile impact and labeling
- Engineered for ICC compliance and optimum safety
- Fabricated from 3/16" carbon steel or schedule 40 steel with industrial coating and SRI 88.2
- Dome shaped to dampen shock to roof drain sump
- Overflow drain available
- Steel or polymer body & dome
- Three Year Warranty
MODELS SIZES
CRD-4 4"
CRD-6 6"
CRD-8 8"
CRD-10 10"
OPTIONS: COFRD(Overflow roof drain); Pre-cast installation; Poured-in-place
Keywords: Cyclone, roof penetration housings, pipe penetration hood, storm shelter, safe room, pipe portal, aluminum curb, gas portal, electrical portal, conduit portal, FEMA P-361, ICC-500

Technical specification

Unique ref.rph-crd
Product familyExterior Protection of Openings
Product groupCyclone Models
TypeObject (single object)
Date of publishing2018-11-28
Edition number1

Links

Product urlhttps://rphproducts.com/products/cyclone/
Installation instructionshttps://roofpenetrationhousings.com/downloads-registration/

Material mainSteel
Designed inUnited States
Manufactured inUnited States

Classification

BIMobject CategoryConstruction - Roof Accessories
UNSPSC nameRoofing accessories
UNSPSC code301516
CSI MasterFormat 2014 Code07 72 00
CSI MasterFormat 2014 TitleRoof Accessories
OmniClass Number23-17 21 11
OmniClass TitleExterior Protection of Openings
