Underground Tank Carat XL

The Carat XL rainwater underground tank has been specially developed for rainwater harvesting. It is available in sizes 8,500 and 10,000 l, vehicle or lorry-bearing (combined with Telescopic dome shaft with cast iron lid or TRUCK).

Optimal tank geometry and statics due to CAD product development – equals highest stability
Unique fitting accuracy of the components
Dome opening with stainless steel profile for precision fit and secure mounting
Consistent quality due to constant production monitoring
Vehicle or lorry-bearing (combined with Telescopic dome shaft with cast iron lid or TRUCK)
Groundwater stable up to the middle of the tank thanks to extremely stable construction
Can be expanded as required

Specification

Carat XL underground tank

Carat XL underground tank (8,500 and 10,000 litres) for rainwater harvesting.

Seamless made of high-quality polyethylene (PE-LLD) - 100 % recyclable - made of one piece.

Truck passable up to SLW 12.

Numerous connection options DN 100/150/200. Larger connection pipes up to DN 300 on request.

Dome opening with rotated stainless steel ring - patented - for extreme stability as well as highest fitting

accuracy and assembly safety.

Large entrance dome (360° rotatable) according to DIN 1989.

Access opening Ø 800/650 mm, H = 610 mm.

Sealed up to the top edge of the terrain in connection with telescopic dome shaft and profile seal.

Tank casing with round grain gravel (max. grain size 8/16). Note the details in our instructions.

Fabricate: GRAF Carat XL underground tank

Volume [l]	Length [mm]	Width [mm]	Height [mm]	Weight [kg]
8500	3500	2040	2695	380
10000	3520	2240	2895	455
13000	4000	2420	3075	600

Technical specification

Unique ref.Underground-Tank-Carat-XL
TypeObject (single object)
Date of publishing2026-03-19
Edition number1
