Clamp-Tite Aluminum Box Scupper

Menzies Metal Products

Clamp-Tite Aluminum Box Scupper

4.5(8 reviews)

Clamping collar to secure membrane to flange.
Full 4″ flange , 4” x 4” x 17” outlet box with an overflow and cleanout box.
Outlet box can be trimmed to wall thickness.
Longer outlet boxes available.
3” insert size pipe in the overflow and cleanout box.
No need to cut an oversized hole to pass the scupper through the wall.
The all-in-one overflow and clean out box will be attached to the outlet box on the exterior of the finished wall.
Stainless steel fasteners.
Listed to meet Canadian and U.S. standards by QAI. Meets CSA B79 and ASME A112.6.4.
Also available in TPO Direct Weld™
STRAINER KIT AVAILABLE

Technical specification

Unique ref.clamptite-boxscupper-aluminum
Product familyFlat Roofing Products
Product groupClamp-Tite Aluminum Box Scupper
TypeObject (single object)
Date of publishing2019-10-01
Edition number1

Links

Product urlhttps://www.menzies-metal.com/flat-roofing/clamp-tite-aluminum-box-scupper/
Installation instructionshttps://www.menzies-metal.com/wp-content/uploads/2019/02/Clamp-Tite-Aluminum-Box-Scupper-Instr-11272013.pdf
Instruction videohttps://youtu.be/-4NGAAdt0PI
Product certificationhttps://qai.org/directory/menzies-metal-products-2/
Technical descriptionhttps://www.menzies-metal.com/wp-content/uploads/2019/02/3-in-Box-Clamp-Scupper-Aluminum-V5-07012017.pdf

Related

Material mainAluminium
Designed inCanada
Manufactured inCanada

Classification

BIMobject CategoryPlumbing - Drainage
IFC classificationObject
UNSPSC nameRoofing drains
UNSPSC code30151605
CSI MasterFormat 2014 Code22 14 26.13
CSI MasterFormat 2014 TitleRoof Drains
OmniClass Number23-13 41 39
OmniClass TitleRoof Drains
CSI UniFormat II CodeD2040
CSI UniFormat II TitleRain Water Drainage

Region availability

North America
Canada
United States
