    Forbo Flooring Systems

    Tessera Inline

    Tessera Inline is a durable, linear textured carpet tile with a soft geometric design, ideal for busy workplace and education environments. The 50x50 cm multi-height loop texture carpet tiles are available in 12 tonal colours.
    Tessera Inline shares its colour tones with the Tessera Layout & Outline collection, making zoning, transitions and cohesive design schemes effortless across any space.

    • 100% solution-dyed polyamide
    • 62% recycled content by weight
    • less than 3.82 kg CO2 e/m2 of embodied carbon (A1–A3)
    • 25 dB impact acoustic value for minimal noise transmission

    Specification
      • Tufted multi-pile height loop carpet tile
        Tile size: 50 x 50 cm
        Packaging per carton of tiles: 16 (4 m²)
        Installation method: monolithic, quarter turn or tessellated
        Classification commercial use: class 33
        Total thickness: 6.5 mm
        Pile height: 3.9 mm
        Total weight: 3895 g/m²
        Pile weight: 605 g/m²
        Pile composition: 100% polyamide 6
        Dye method: 100% solution dyed
        Stitch density: 198,374 per m²
        Primary backing: polyester
        Acoustical impact noise reduction: 25 dB
        Acoustical sound absorption: αw = 0.20 (H)
        Castor chair continuous use: r ≥ 2.4
        Colour fastness to light: ≥ 5
        Dimensional stability: ≤ 0.2%
        Indoor air emissions: TVOC after 28 days: ≤ 0.1 mg/m3
        Recycled content: 62% recycled content by weight
        Tessera carpet tiles are manufactured using 100% renewable energy (electricity & biogas)
        Indoor air quality: Inline carpet tiles comply to Indoor Air Comfort Gold 8.0 (2022)
        Ska rating: M12 soft floor coverings in office, retail and higher education schemes
        Prodis-GUT: Inline carpet tiles meet the test criteria of GUT
        Reaction to fire (EN 13501-1): Bfl-s1, G, NCS
        Slip resistance (EN 13893): μ ≥ 0.30
        Body voltage (ISO 6356): < 2 kV
        Thermal conductivity (EN 12524): 0.06 W/mK

        All Forbo Flooring Systems’ sales organisations and manufacturing sites worldwide have certified Quality Management Systems in accordance with ISO 9001. All Forbo Flooring Systems’ manufacturing plants have certified Environmental Management Systems in accordance with ISO 14001. Tessera carpet tiles are manufactured in a facility certified to SA8000® and ISO 45001.
        The Life Cycle Assessment (LCA) of Forbo Flooring Systems’ products is documented in individual Environmental Product Declarations (EPD’s).

    Technical specification
    • Unique ref.FO-TE-IN
    • Product familyFlooring
    • Product groupCarpet Tiles
    • TypeObject (single object)
    • Date of publishing2016-05-12
    • Edition number1
    • Height (mm)500
    • Width (mm)500
    • Depth (mm)6.5
    Links
    Related
    • Material mainPolyamide
    • Material secondaryPolyester
    • Designed inUnited Kingdom
    • Manufactured inUnited Kingdom
    • Weight Net (Kg)3.9
    Classification
    • BIMobject CategoryFlooring - Carpets
    • IFC classificationFloor
    • Uniclass 2015 CodeEF_30_20
    • Uniclass 2015 DescriptionFloors
    • CSI MasterFormat 2014 Code09 68 13
    • CSI MasterFormat 2014 TitleTile Carpeting
    • OmniClass Number23-15 17 17 13
    • OmniClass TitleCarpet Tiles
