Dwide corner

Description:

Corner-mounted luminaire with direct light distribution.

Metal luminaire body with die-cast metal ends, white (RAL 9016) finish.

Key Features:
Lumen: 2000lm, 2900lm
Colour temperature: 3000K, 4000K
Light distribution: Direct
Voltage: 220-240V
CRI: 80
IP: 20
IK:
Standard Colours: White
Available Light control: DALI/Phase-pulse, Organic Response, e-Sense Flex

Specification

Specification

Dimension: 66, 126, 1164 | 71, 126, 1240 | 66, 126, 1240
Weight: 3.6 kg
SDCM: 3
LED driver, h/max failure: 100000/10
Tilt:
Turn:

Connection:

Installation
For mounting where the ceiling and wall meet. Installed against the wall or ceiling.

Louvre
Delta – microprism louvre in acrylic (PMMA) with a thin opal diffuser in acrylic (PMMA) inside. Light divider in acrylic (PMMA).

Optics
