SOLEAL Next 65 Visible open-in

SOLEAL Next 65 Visible open-in

SOLEAL Next 65 Visible open-in

The visible structure is balanced between the fixed frame and the opening vent, providing an additional aesthetical touch to the window.

Multiple applications
Aesthetic offer with wide choice internal and external profiles
Large choice of colours and accessories
Concealed hardware, handle and drainage
Effective thermal, acoustic and weather tightness performances
Large sizes
Reliable safety features
Reduced threshold for persons with disabilities

Specification

Diversity of applications :
- Openings: side hung, tilt, tilt & turn
- Façade and other ranges integration
- Composite assemblies
- Horizontal and vertical pivot
- Patio window
- Juliet balcony
- Motorised available for tilt
- Magnetic window contact
- Building management system: concealed locking sensor
- Security glazing beads
- Antibacterial coating on handles
- Reduced threshold for disabled: 15-20 mm
High performnces :
- Thermal: Uw up to 0,93 W/m²K
- Air permeability: Class 4
- Water tightness: Class 1500
- Wind pressure resistance: Class 5
- Acoustic performance: Rw up to 47 dB
- Burglary resistance up to RC2, RC3 and PAS24
Larges sizes :
- Height: up to 3 meters
- Glazing thickness: up to 59 mm
- Infill weight: up to 160 kg
Sustainability :
- SOLEAL Next is made in Hydro CIRCAL®, aluminium made with a minimum of 75% recycled end-of-life aluminium.
- 75% recycled and 95% recyclable
- PVC-free components
- Cradle to Cradle®: under certification
- Dynamic EPD available on TechDesign

Technical specification

Unique ref.soleal-next-65-visible-open-in
Product familyWindows & Doors
Product groupWindows
TypeObject (single object)
Date of publishing2026-02-26
Edition number1

Links

Product urlhttps://www.domal.it/it-it/professionisti/prodotti/finestre-portefinestre/soleal-next-65

Related

Material mainExtruded Aluminum
Material secondaryGlass
Designed inItaly
Manufactured inItaly

Classification

BIMobject CategoryWindows - Casement Window
IFC classificationWindow

Region availability

Europe
Italy
