Digger Specialties, Inc.

Veranda Glass Series Deck Railing

Beauty meets strength. Elegance meets distinction. Masterpiece meets innovative engineering. Westbury® Aluminum Deck Railing was designed with these essential elements in mind. With a variety of designs, colors, and textures, you decide what fits you. Whether you add railing to the front of your home or to the deck in the back, you will have turned your home into a very welcoming retreat. Veranda (C70) creates a phenomenal viewing area. The crystal clear design incorporates full glass panels into the classic 2 rail design. Whether you have a view of land or water, Veranda gives you an open concept with the security of full railing sections. Railing sections do not come with glass panels. Panels must be ordered separately. DSI offers A clear Standard Glass Panel and Bronze and Grey panels as a special order. Optional 3/8" Tempered Glass Rails are available. DSI does not offer 3/8" tempered glass.

Specification

Railing Heights:	36” and 42”
Railing Lengths:	4', 5’, and 6’
Stair Rail Lengths:	All Stair Rails are Custom Ordered
Post Dimensions:	2" Residential Post (.090" Wall) 2" Heavy Duty Post (.093" Wall) 2 1/2" Residential Post (.125 Wall) 2 1/2" Power Post (.125" Wall) 3" Residential Post (.095 Wall) 4" Smooth Post (.125" Wall) 4" Deco Post (.090" Wall) 6" Deco Post (.090" Wall)
Post Applications for Straight Sections	36" T Straight Railing sections require a 37" T post or a 36" T Crossover post. 42" T Straight Railing sections require a 43" T post or a 42" T Crossover post
Post Applications for Stair Sections	36" T Stair Railing sections require a 47" T post. 42" T Stair Railing sections require a 53" T post. If the crossover feature is utilized the optional Crossover Adapter is required
Glass Panel:	¼" Tempered Glass. Standard Glass Panel Color: Clear. Special Order Colors: Bronze and Grey
Stylish Top Rail:	1 3/4” w (.085”) x 1 3/8” t (.085”)
Bottom Rail:	1 3/4” w (.085”) x 1 1/4” t (.085”)
Gates:	Welded Gates: 36", 48", and 60" w openings. Custom sizes are available through Tech Services.
