12" Tee Cap w/Drain

InnoFlue Tee Cap with Drain provide a versatile solution designed to optimize your exhaust system's performance and easily drain condensates. Rated to 230°F (110°C), The integrated 30 mm drain connects to InnoFlue siphons to efficiency evacuated moisture from the system while maintaining operational efficiency. InnoFlue Tee Caps with Drain are a part of InnoFlue's Condensate Management Portfolio.

Integrated 30mm drain connects with InnoFlue Siphon
Helps to efficiently manage condensates
Evaluated to UL1738 and ULCS636 by ICC.
Installs quickly & easily without glues, primers, or solvents.
Rated to 230°F (110°C).

Specification

SpecificationsGeneralProduct Name12" Tee Cap w/DrainTrade nameInnoFlueGTIN0815010012901Part number250407703440TechnicalColorGrayMaterialPPsSystem typeSingle wallShapeCircularDimensionsLength gross373.38 mm / 14.7 inchHeight350.52 mm / 13.8 inchDiameter flue pipe315 mm / 12 inchWidth350.52 mm / 13.8 inchNet weight4.08 kg / 9 lbsLogisticalIntrastat3917400090Base unit packagingUnpackedPackaging / Trade length373.38 mm / 14.7 inchPackaging / Trade height350.52 mm / 13.8 inchNumber per packaging1Gross weight4.082 kg / 9 lbsPackaging / Trade width350.52 mm / 13.8 inchPerformanceTemperature resistance (max.)120 °CCertificationCertificates (US/CAN)UL 1738 – ICC-ES / ULC S636 – ICC-ES

Technical specification

Unique ref.12-teecapw-drain
Product familyCommon Venting and Condensate Managemenet
Product groupSingle Wall - Large diameter
TypeObject (single object)
Date of publishing2025-09-02
Edition number1

Links

Product urlhttps://www.centrotherm.us.com/products/innoflue-polypropylene-vent-systems/single-wall-large-diameter/common-venting-and-condensate-management/12-tee-cap-w_drain/

Designed inUnited States
Manufactured inUnited States

Classification

BIMobject CategoryHVAC - Ductwork
IFC classificationDuct Fitting
ETIM CodeEG015540
ETIM NameFittings, flanges and connectors
Uniclass 2015 CodePr_65_65_25
Uniclass 2015 DescriptionDuctwork and fittings
CSI MasterFormat 2014 Code23 31 13.19
CSI MasterFormat 2014 TitleMetal Duct Fittings
OmniClass Number23-33 49 00
OmniClass TitleHVAC Ductwork
