Eversky Q

EVERSKY™Q, ultra Quiet self-regulating decentralized ERU, high efficiency counter-flow exchanger.

Intended for room-by-room installations. Particularly suitable for renovation, no airducts required : classrooms, nurseries, offices and shops.
The EVERSKY™Q unit is based on 2 patented innovations for more performance and simplicity of installation:
- Patented support frame for quick and easy installation
- Patented removable panels for safe handling and a wide choice of airflow configurations

Equipped, as standard, with an EASY control system with integrated CO2 sensor to maintain optimal High Indoor Air Quality, communicating in ModBus, BACnet or web (to be selected on site)

Mobile and hinged hinges opening from below for easy maintenance and quick access to filters and all components of the unit
Direct drive EC motor.
CLEARDUST™ device / Double stage filtration on Fresh Air for High Indoor Air Quality (in option).
Airflows from 100 to 1 100 m³/h

Available in right-hand (R) and left-hand (L) version

Specification

EVERSKY™, decentralized self-regulating heat recovery unit, for room-by-room applications, high efficiency (90%).
MODBUS, BACNET or WEB communicating.
Self-supporting structure, external RAL9010 double skin envelope insulated with 25mm M0 high density mineral wool (60 kg/m3).
Fitted with a EUROVENT-certified aluminium counterflow heat exchanger, F7 (fresh air) and M5 ( extracted air) filters mounted on a sealed slide ( optional double filtration on fresh air for F7+M5/F9), 100% motorised bypass for free-cooling and night-cooling, 4 integrated sensors.
Patented removable panels for numerous airflow configurations.
Quick and easy full visible or recess under false ceiling mounting with patented support frame.
Acoustic data available on our SOFTWAIR™ selection tool and approved by the Peutz laboratory in test.
Freewheeling fans and low-consumption EC fans.
Lockable mains power cut-off switch LCD control in "EASY™" control box.
Dual seal round spigots to guarantee airtightness of networks (ATEC CSTB n° 13-224-V2).
Fire safety function (except SEASON) to control supplied and extracted air fans.
Integrated condensate drain tray inclined with a 2% slope for easy installation.
100% PLUG&PLAY range.

Technical specification

Unique ref.eversky-q
Product familyHVAC
Product groupEVERSKY
TypeObject (single object)
Date of publishing2025-07-29
Edition number1
Height (mm)561
Width (mm)2406
Depth (mm)1426

Material mainSteel
Designed inFrance
Manufactured inFrance
Weight Net (Kg)240

Classification

BIMobject CategoryHVAC - Heat Recovery
IFC classificationHeat Exchanger
ETIM CodeEC011286
ETIM NameHeat recovery unit
Uniclass 2015 CodePr_60_65_03_87
Uniclass 2015 DescriptionSupply and return air handling units
OmniClass Number23-33 25 00
OmniClass TitleAir Handling Units
