BETAFENCE Betaview Securifor Super 6 3D + Bekafix Plus
Betafence

BETAFENCE Betaview Securifor Super 6 3D + Bekafix Plus

Manufactured in South Africa

BETAVIEW®
Securifor®
Super 6 3D

Effective protection
Securifor® Super 6 3D is an imposing fence made from 4mm horizontal wires (4.4mm when costed) and 5.6mm vertical wires (6mm when coated). Available in heights of up to 3m it effectively protects against breach attempts, especially when combined with detection and electrification systems.

Breakthrough and vandal resistant

Heavy wires, robust welding and small apertures make it very time consuming to cut through and difficult to climb.

Visibility

Despite the small mesh apertures, the fence appears almost invisible from a distance, even at an angle. It is ideal for use with surveillance systems.

Electric Fence Compliant

Panel widths meet the maximum distance requirement for electrical fence installation compliance.

Full system 10-year guarantee
(standard terms & conditions apply)
Superior coatings underpin our 10-year anti-corrosion guarantee when Betafence’s full system
(panels, posts, and stainless steel fixators) is used.

Specification
  • Panels
    Wire Diameter: 4mm/5.6mm Zincalu® Super (4.40mm/6mm PVC coated)
    The small apertures and thicker vertical wires make the fence difficult to cut and climb.
    Available in 3m wide panels and two standard height options
    ** Other heights available on request.

    Available Wire Diameters -
    5.65mm/5.65mm (6/6 Coated)
    5.65mm/3.96mm (6/4.36 Coated)
    5.65mm/3.65mm (6/4 Coated)
    5.65mm/3mm (6/3.4 Coated)

    Posts & Fixing Mechanisms
    The Securifor Super 6 3D system are installed with Bekafix Plus Posts. The fence is safely tucked behind the lip of the post,resisting against attempts to pry the panel loose from the post. The panels are secured to the post with our Spider fixators, firmly bolted through the post using M8 stainless steel security bolts and shear-off nuts that protect against tampering.
    This combination of Betafence panels with Bekafix Plus post and superior fixing mechanisms delivers a complete fencing system that ensures the installation’s integrity and protection levels. Increase your perimeter’s protection by adding sawtooth top rails to further
    discourage climbing attempts. Extended posts and brackets are available to accommodate additional security features such as electric fencing*, flat wrap razor, or BTC coil toppings.

Technical specification
  • Unique ref.betafence-betaview-SecuriforSuper-6-3D-BekafixPlus
  • Product familyMetal Fence Panel
  • Product groupBetaview System
  • TypeObject (single object)
  • Date of publishing2022-10-28
  • Edition number1
Links
Related
  • Material mainSteel
Classification
  • BIMobject CategoryLandscaping - Fencing
